Curator - David G. Larsen

Italian Book Series

DESIGN OF OP-AMP CIRCUITS, WITH EXPERIMENTS

ISBN:0-672-21537-3

Authors:Howard M. Berlin

Publisher:Howard W. Sams & Co., Inc.4300 West 62nd St.

Indianapolis, IN 46268

Copyright:1977

The op-amp is one of the most versatile integrated circuits in use. This book is about the design and operation of basic operational-amplifier circuits. It is a text-/workbook that explains the design of the fundamental circuits that are the building blocks of more sophisticated systems using many op-amps. The basic op-amp circuits covered in this book include: linear amplifiers, differentiators and integrators, voltage and current converters, comparators, rectifiers, oscillators, active filters, and single supply circuits. Included in the text are 37 experiments to illustrate the design and operation of these circuits. Chapter 1 defines an op-amp and discusses the many parameters the distinguish one type of op-amp from another. Basic linear amplifier circuits using op-amps are covered in the second chapter. Two additional basic op-amp circuits, the differentiator and the integrator, are presented in Chapter 3. Some of the basic op-amp voltage and current circuits are discussed in Chapter 4. The next chapter presents several nonlinear signal processing circuits using co-amps. Chapter 6 discusses the application op-amps to generate various kinds of simple waveforms. Several of the major active-filter configurations using op-amps are presented in Chapter 7. The eighth chapter discusses methods by which op-amp circuits can be operated from a single supply voltage. The Norton op-amp, or current-differencing amplifier, which is designed to operate from a single-ended power supply, is covered in chapter 9.

Finally, Chapter 10 describes a different type of integrated-circuit amplifier, the instrumentation amplifier.
